DT Swiss FR 541 DB 29" rim
Item number: 213198
Product Description
DT Swiss FR 541 rim – robust aluminium freeride rim in silver
The DT Swiss FR 541 is a strong freeride rim for demanding use on rough trails. Its revised rim shape improves impact resistance and increases puncture protection, giving you reliable performance on challenging terrain.
With a 30 mm internal width, the aluminium rim provides modern tyre support for wide MTB tyres. The welded rim joint, PHR system and hooked tubeless tyre interface make the FR 541 a durable base for tough freeride and e-MTB wheels.
Guidelines for Replacing E-bike Components:
Before you replace components on your e-bike, please read through the guidelines for component replacement for CE-marked e-bikes/pedelecs with pedal assistance.
Product Specifications:
- Tubeless system:
- Tubeless Ready
- Valve hole (diameter):
- SV (6.5 mm)
- Rim material:
- Aluminum
- Inner rim width:
- 30 - 30 mm
- Outer rim width:
- 35 - 35 mm
- Rim flange:
- With hook
- ERD (Effective Rim Diameter):
- 603 mm
silver | 32 | 29":
- Rim height:
- 30 mm
- Wheel size:
- 29"
Technical Information:
silver | 32 | 29":
- Number of Holes:
- 32
Product Features:
• Robust aluminium rim for freeride use
• ASTM classification 5 for demanding off-road loads
• Welded rim joint for high stability
• Hooked / crotched tubeless tyre interface
• 30 mm internal width and 35 mm external width
• Disc brake specific
• 32 spoke holes
• Non-eyelet PHR spoke interface
• Presta valve hole
• Approved for e-bikes up to 32 km/h or 250 W
• Maximum system weight: 140 kg
• Includes Pro Lock brass nipples and PHR washers
• Colour: silver
• Weight: 605 g
• ASTM classification 5 for demanding off-road loads
• Welded rim joint for high stability
• Hooked / crotched tubeless tyre interface
• 30 mm internal width and 35 mm external width
• Disc brake specific
• 32 spoke holes
• Non-eyelet PHR spoke interface
• Presta valve hole
• Approved for e-bikes up to 32 km/h or 250 W
• Maximum system weight: 140 kg
• Includes Pro Lock brass nipples and PHR washers
• Colour: silver
• Weight: 605 g
Manufacturer Number:
- silver | 32 | 29": RDFR54CDPW32NA8805
Contents:
- 1 x DT Swiss FR 541 DB 29" Rim
