Fox Racing Shox 36 Float 29" GRIP X2 Factory Boost E-Optimised suspension fork
Product Description
36 Float 29" GRIP X2 Factory Boost E-Optimised Suspension Fork by Fox Racing Shox
The 36 Float 29" GRIP X2 Factory Boost E-Optimised Suspension Fork by Fox Racing Shox is designed for all-mountain MTB riding, delivering precise control and adaptability on varied terrain. With a sturdy aluminum steerer tube and crown, combined with magnesium lower legs, this fork offers a lightweight yet durable build. Its 36 mm aluminum stanchions ensure smooth performance, while the air pressure spring rate allows you to fine-tune your ride. The fork features both low-speed and high-speed rebound and compression damping for optimal responsiveness. It fits 29" wheels with a 15 x 110 mm Boost thru axle system and supports disc brakes up to 230 mm diameter. Ready for e-bikes and pedelecs up to 25 km/h, it provides reliable performance on demanding trails. The 244 mm steerer tube length suits a wide range of setups. This suspension fork is a solid choice for riders seeking dependable handling and adjustability in challenging mountain conditions.
Guidelines for Replacing E-bike Components:
Product Specifications:
- Application:
- All Mountain, MTB
- Wheel size:
- 29"
black | 160 mm | 44 mm | 110 mm | 29" | 1 1/8" - 1,5" tapered | 15 mm Thru Axle:
- Travel:
- 160 mm
- Wheel size:
- 29"
Technical Information:
- Steerer Tube Length:
- 244 mm
- Steerer Tube Material:
- Aluminum
- Spring Rate:
- Via Air Pressure
- Travel Adjustment:
- No
- Steerer Tube Diameter (Crown Race):
- 40 mm
- Brake Mount:
- Disc PM8 (Direct Mount 203 mm)
- Stanchion Tube Diameter:
- 36 mm
- Compression Damping:
- High-Speed and Low-Speed
- Stanchion Material:
- Aluminium
- Axle System:
- Thru Axle (15 x 110 mm)
- Rebound Damping:
- Yes, Low-Speed and High-Speed
- Crown Material:
- Aluminum
- Remote:
- No
- Lower Leg Material:
- Magnesium
- Wheel Standard:
- 15 x 110 mm (Boost)
black | 160 mm | 44 mm | 110 mm | 29" | 1 1/8" - 1,5" tapered | 15 mm Thru Axle:
- Fork Offset:
- 44 mm
- Installation Width:
- 110 mm
- Steerer Tube:
- 1 1/8" - 1,5" tapered
- Axle Standard:
- 15 mm Thru Axle
Approved For:
- Max. disc brake diameter:
- 230 mm
Product Features:
- High-performance 36 Float 29" GRIP X2 Factory Boost suspension fork designed for aggressive all-mountain riding and optimized for E-Bikes up to 25 km/h
- Durable aluminum steerer tube and crown combined with lightweight magnesium lower legs for an ideal balance of strength and weight
- Advanced dual compression and rebound damping systems for precise control over both high-speed and low-speed impacts
- Boost 15 x 110 mm thru-axle ensures maximum stiffness and improved handling on 29" wheels
- Compatible with 203 mm direct mount disc brakes and supports up to 230 mm rotor diameter for powerful stopping power
Manufacturer Number:
- black | 160 mm | 44 mm | 110 mm | 29" | 1 1/8" - 1,5" tapered | 15 mm Thru Axle: 910-21-427
Contents:
- 1 x Fox Racing Shox 36 Float 29" GRIP X2 Factory E-Optimized suspension fork
