Schwalbe Inner Tube 20 Extralight 28"

Extra light inner tube for 28" tyres. Same reliability, reduced weight. Tried and tested over many years.

Specifications:

Application:

Road

ETRTO:

18-622 to 25-630

Tyre Dimensions:

28 x 3/4 to 27 x 1.0"

Inner Tube Material:

butyl

Valve Type:

SV / Presta 40 mm, SV / Presta 50 mm, SV / Presta 60 mm, SV / Presta 80 mm

Dimensions (ETRTO):

• 28 x 3/4 = 700 x 18c (18-622)
• 28 x 3/4 = 700 x 20c (20-622)
• 28 x 7/8 = 700 x 22c (22-622)
• 28 x 7/8 = 700 x 23c (23-622)
• 28 x 1.00 = 700 x 25c (25-622)
• 27 x 7/8 (22-630)
• 27 x 1.00 (25-630)

Note from the manufacturer:

This inner tube may only be used with rims with a maximum inner jaw width of 19 mm.

Models:

18/25-622/630 SV / Presta 40 mm

Valve Type:

SV (Sclaverand/Presta)

Valve Length:

40 mm

Type:

SV20

Manufacturer Number:

10426343

18/25-622/630 SV / Presta 50 mm

Valve Type:

SV (Sclaverand/Presta)

Valve Length:

50 mm

Type:

SV20

Manufacturer Number:

10400103

18/25-622/630 SV / Presta 60 mm

Valve Type:

SV (Sclaverand/Presta)

Valve Length:

60 mm

Type:

SV20

Manufacturer Number:

10426363

18/25-622/630 SV / Presta 80 mm

Valve Type:

SV (Sclaverand/Presta)

Valve Length:

80 mm

Type:

SV20

Manufacturer Number:

10426383

Valve Information

Tubes are available with various valve types.
Choosing a valve is dependent on application and the rim's valve hole diameter.

SV / Presta Valve:

• Synonyms: Sclaverand Valve (SV), French Valve, Presta Valve
• Outer Diameter: 6.5 mm
• Other: all Schwalbe tubes with a Presta valve can be unscrewed. (To lengthen the valve, add anti-flat agents, etc.)

Technology:

Inflation Pressure Stability
A Schwalbe inner tube maintains the air much longer. The quality of the inner tube is already determined by its raw materials, through the ingredients and the purity of the rubber compound. During vulcanisation, each Schwalbe inner tube is placed in a mould and is then inflated. This is the only way to ensure a uniform wall thickness and excellent air retention.

Reliability
Rigorous monitoring that ensures the best operational reliability: each inner tube is inflated in the fabric and stored under pressure for 24 hours to check the air retention ability.

Tube Groups System
Due to its high elasticity and quality, a single inner tube covers a large number of tyre sizes. For example, inner tube no. 17 works just as well for 28 mm wide tyres as for 47 mm wide tyres. Only an extremely high-quality and reliable inner tube can meet this requirement.

Contents:

• 1 x Schwalbe 20 Extralight inner tube
