Specialized Turbo Vado X3 4.0 27,5" e-trekking-bike
Item number: 246114
Product Description
Turbo Vado X3 4.0 27,5" e-trekking-bike by Specialized for City & Touring Adventures
The Turbo Vado X3 4.0 27,5" e-trekking-bike from Specialized is designed for City & Touring applications, offering a perfect blend of performance and comfort. Equipped with a powerful Specialized 3.1 mid-drive motor and a high-capacity 840 Wh Specialized Turbo X2 battery, it delivers reliable assistance up to 25 km/h. The carbon frame ensures a lightweight yet sturdy ride, complemented by Specialized Hemisphere Allterrain Reflex tires (27.5 x 2.6") for excellent grip on varied surfaces. Hydraulic Tektro HD-T5040 disc brakes provide confident stopping power in all conditions. The bike features a 10-speed Shimano Cues trigger shift system with an 11-48T cassette, allowing smooth and precise gear changes. Comfort is enhanced by the Body Geometry Rivo 2 Gel saddle and Specialized Body Geometry Contour grips, while the integrated rear rack mounts and aluminum Specialized Drytech mudguards add practical utility. The Specialized Turbo Ergonomic display keeps you informed and in control throughout your ride. With a kickstand and Specialized Turbo pedals with anti-slip design, this e-trekking bike is ready for your urban and touring adventures.
Information regarding the return of batteries and electrical equipment:
Information on the return and disposal of used batteries and electrical equipment can be found here. For information regarding the return of used e-bike batteries, please contact our customer service.
Product Specifications:
- Brake Type:
- disc
- Application:
- City & Touring
- Frame material:
- Carbon
- Gender:
- Women's, Men´s
gloss obsidian-satin silver dust frost | S | 170,0 mm | 44 mm | 27.5" (650B):
- Crank Arm Length:
- 170,0 mm
- Wheel size:
- 27.5" (650B)
gloss obsidian-satin silver dust frost | M | 170,0 mm | 44 mm | 27.5" (650B):
- Wheel size:
- 27.5" (650B)
- Crank Arm Length:
- 170,0 mm
gloss obsidian-satin silver dust frost | L | 170,0 mm | 44 mm | 27.5" (650B):
- Crank Arm Length:
- 170,0 mm
- Wheel size:
- 27.5" (650B)
gloss obsidian-satin silver dust frost | XL | 170,0 mm | 44 mm | 27.5" (650B):
- Crank Arm Length:
- 170,0 mm
- Wheel size:
- 27.5" (650B)
Technical Information:
- Seatpost diameter:
- 34,9 mm
gloss obsidian-satin silver dust frost | S | 170,0 mm | 44 mm | 27.5" (650B):
- Fork Offset:
- 44 mm
gloss obsidian-satin silver dust frost | M | 170,0 mm | 44 mm | 27.5" (650B):
- Fork Offset:
- 44 mm
gloss obsidian-satin silver dust frost | L | 170,0 mm | 44 mm | 27.5" (650B):
- Fork Offset:
- 44 mm
gloss obsidian-satin silver dust frost | XL | 170,0 mm | 44 mm | 27.5" (650B):
- Fork Offset:
- 44 mm
E-Motor:
- Battery Type:
- Specialized Turbo X2
- Max. Assistance Speed:
- 25 km/h
- Power:
- 810
- Motor Manufacturer:
- Specialized
- Motor Type:
- Specialized 3.1
- Display:
- Specialized Turbo Ergonomic
- Version:
- Mid-Drive Motor
- Capacity:
- 840
Components:
- Crankset:
- Specialized Custom, 48 teeth
- Saddle:
- Body Geometry Rivo 2 Gel
- Pedals:
- Specialized Turbo, anti-slip
- Front Derailleur:
- without
- Rear Hub:
- 12 x 148 mm, Thru Axle
- Front Hub:
- 15 x 110 mm, Disc 6-Bolt
- Rear Wheel Tyre:
- Specialized Hemisphere Allterrain Reflex, 27,5 x 2,6"
- Rear Light:
- integrated rack mounts
- Headlight:
- Lezyne E-Bike E500+
- Seatpost:
- Specialized
- Chain:
- Shimano
- Derailleur:
- Shimano Cues 11-speed
- Rims:
- Specialized
- Front Wheel Tyre:
- Specialized Hemisphere Allterrain Reflex, 27,5 x 2,6"
- Mudguards:
- Specialized Drytech, Aluminum
- Brakes:
- Tektro HD-T5040, hydraulic
- Grips:
- Specialized Body Geometry Contour
- Shift Lever:
- Shimano Cues Trigger, 10-speed
- Cassette:
- Shimano CUES CS-LG400, 11-48 T, 10-speed
- Kickstand:
- yes
gloss obsidian-satin silver dust frost | S | 170,0 mm | 44 mm | 27.5" (650B):
- Brake Discs:
- Tektro TR
- Stem:
- Specialized integrated Display
- Handlebar:
- Specialized Alloy
- Fork:
- SR Suntour Mobie 35
gloss obsidian-satin silver dust frost | M | 170,0 mm | 44 mm | 27.5" (650B):
- Fork:
- SR Suntour Mobie 35
- Brake Discs:
- Tektro TR
- Stem:
- Specialized integrated Display
- Handlebar:
- Specialized Alloy
gloss obsidian-satin silver dust frost | L | 170,0 mm | 44 mm | 27.5" (650B):
- Handlebar:
- Specialized Alloy
- Fork:
- SR Suntour Mobie 35
- Brake Discs:
- Tektro TR
- Stem:
- Specialized integrated Display
gloss obsidian-satin silver dust frost | XL | 170,0 mm | 44 mm | 27.5" (650B):
- Fork:
- SR Suntour Mobie 35
- Brake Discs:
- Tektro TR
- Stem:
- Specialized integrated Display
- Handlebar:
- Specialized Alloy
Approved For:
- Max. Fork Length:
- 531 mm
Product Features:
- Powerful and versatile Turbo Vado X3 4.0 E-Trekking bike designed for city and touring adventures with a lightweight carbon frame and mid-drive motor.
- Equipped with a high-capacity 840 Wh Specialized Turbo X2 battery for extended rides and reliable power support up to 25 km/h.
- Features Specialized Hemisphere Allterrain Reflex 27.5 x 2.6" tires and hydraulic Tektro HD-T5040 disc brakes for excellent traction and stopping power in diverse urban and trail conditions.
- Lezyne E-Bike E500+ headlight and rear rack mounts with built-in rear light ensure safety and visibility during day and night rides.
- Smooth and precise shifting with Shimano Cues 10-speed trigger shifters, Shimano Cues 11-speed derailleur, and a robust Specialized Custom crankset with 48 teeth for optimal pedaling efficiency.
Geometry:
gloss obsidian-satin silver dust frost | S | 170,0 mm | 44 mm | 27.5" (650B):
- Head Tube Angle:
- 66
- Stack:
- 618 mm
- Standover Height:
- 747 mm
- Wheelbase:
- 1212 mm
- Reach:
- 430 mm
- Chainstay Length:
- 473 mm
- Seat Tube Angle:
- 74
- BB Drop:
- 30 mm
- Seat Tube Length:
- 390 mm
- Head Tube Length:
- 131 mm
- Bottom Bracket Height:
- 330 mm
- Stem Length:
- 60 mm
- Flat Bar Width:
- 730 mm
- Effective Top Tube Length:
- 665 mm
gloss obsidian-satin silver dust frost | M | 170,0 mm | 44 mm | 27.5" (650B):
- Head Tube Angle:
- 66
- Stack:
- 625 mm
- Standover Height:
- 747 mm
- Wheelbase:
- 1235 mm
- Reach:
- 450 mm
- Chainstay Length:
- 473 mm
- Seat Tube Angle:
- 74
- BB Drop:
- 30 mm
- Flat Bar Width:
- 730 mm
- Seat Tube Length:
- 415 mm
- Head Tube Length:
- 139 mm
- Bottom Bracket Height:
- 330 mm
- Stem Length:
- 60 mm
- Effective Top Tube Length:
- 700 mm
gloss obsidian-satin silver dust frost | L | 170,0 mm | 44 mm | 27.5" (650B):
- Head Tube Angle:
- 66
- Stack:
- 640 mm
- Standover Height:
- 747 mm
- Wheelbase:
- 1267 mm
- Reach:
- 475 mm
- Chainstay Length:
- 473 mm
- Seat Tube Angle:
- 74
- BB Drop:
- 30 mm
- Flat Bar Width:
- 730 mm
- Seat Tube Length:
- 435 mm
- Bottom Bracket Height:
- 330 mm
- Stem Length:
- 60 mm
- Head Tube Length:
- 155 mm
- Effective Top Tube Length:
- 607 mm
gloss obsidian-satin silver dust frost | XL | 170,0 mm | 44 mm | 27.5" (650B):
- Head Tube Angle:
- 66
- Stack:
- 667 mm
- Standover Height:
- 747 mm
- Wheelbase:
- 1304 mm
- Reach:
- 500 mm
- Chainstay Length:
- 473 mm
- Seat Tube Angle:
- 73
- BB Drop:
- 30 mm
- Flat Bar Width:
- 730 mm
- Seat Tube Length:
- 460 mm
- Head Tube Length:
- 185 mm
- Bottom Bracket Height:
- 330 mm
- Stem Length:
- 60 mm
- Effective Top Tube Length:
- 632 mm
Manufacturer Number:
- gloss obsidian-satin silver dust frost | S | 170,0 mm | 44 mm | 27.5" (650B): 91627-5502
- gloss obsidian-satin silver dust frost | M | 170,0 mm | 44 mm | 27.5" (650B): 91627-5503
- gloss obsidian-satin silver dust frost | L | 170,0 mm | 44 mm | 27.5" (650B): 91627-5504
- gloss obsidian-satin silver dust frost | XL | 170,0 mm | 44 mm | 27.5" (650B): 91627-5505
Shipping Notice:
The shipment is sent pre-assembled by a forwarding agent.
The delivery time is, depending on the workshop workload, 2 - 5 days in addition to the delivery time shown in the online shop.
For individual consultation, please contact our customer service team.
The delivery time is, depending on the workshop workload, 2 - 5 days in addition to the delivery time shown in the online shop.
For individual consultation, please contact our customer service team.
Contents:
- 1 x Specialized Turbo Vado X3 4.0 E-Trekking-Bike
- 1 x Specialized 4A charger
Weight:
- gloss obsidian-satin silver dust frost | S | 170,0 mm | 44 mm | 27.5" (650B): 30.9 kg
- gloss obsidian-satin silver dust frost | M | 170,0 mm | 44 mm | 27.5" (650B): 30.9 kg
- gloss obsidian-satin silver dust frost | L | 170,0 mm | 44 mm | 27.5" (650B): 30.9 kg
- gloss obsidian-satin silver dust frost | XL | 170,0 mm | 44 mm | 27.5" (650B): 30.9 kg
