absoluteBLACK Oval T-Type Chainring for SRAM Transmission 3 mm Offset

The absoluteBLACK Oval T-Type chainring for SRAM Transmission with 3 mm offset

This oval 1-speed chainring by absoluteBLACK was specially designed for SRAM Eagle transmission drives. It features a special Narrow-Wide tooth profile that works perfectly with the T-Type chains. These are narrower than conventional chains because the distance between the outer and inner plates is smaller, and they have more generously dimensioned rollers. That is why the teeth of the absoluteBLACK T-Type chainring are generally thinner and the spaces between the teeth are more pronounced. In addition, there are specific features that ensure good self-cleaning, such as a horizontal channel on the wide teeth and a specific modification in the area closest to the back of the crank arm. This optimally repels mud, sand and dirt, which is particularly important for narrow chains. The premium quality aluminium chainring is compatible with SRAM XX SL, XX, X0 Eagle Transmission and other cranks with Direct Mount 8-bolt mounts. It has an offset of 3 mm - like the original from SRAM - so it is suitable for a 55 mm chainline. Thanks to the oval shape, you optimise your pedalling movement, reduce the strain on your knees and move forward faster.

Specifications:

Application:

Enduro, All Mountain, Cross Country

Mount:

SRAM Direct Mount

Teeth:

28 T, 30 T, 32 T, 34 T, 36 T

Gearing:

1x12-speed

Type:

Oval 10.2 - 14.4 %

Technical Information:

Offset:

3 mm

Chainline:

55 mm

Material:

aluminium (7075)

Compatibility:

Crank:

SRAM XX SL Eagle Transmission, XX Eagle Transmission, X0 Eagle Transmission with a 8-bolt mount

Chain:

SRAM T-Type Flattop

Features:

• special Narrow-Wide chainring for SRAM Transmission T-Type chains
• thinner teeth due to narrower distance between inner and outer chain plates
• larger space between the teeth due to wider diameter of the chain rollers
• excellent dirt repellency: horizontal channel at about half the height of the wider teeth and modification of one tooth in the area behind the crank arm
• oval shape for improved traction and performance uphill
• faster, looser riding with a natural pedalling motion with reduced strain on the knees
• ovality and timing (110.5 - 116.3°) matched to chainring size (TDC technology, Top Dead Center)
• excellent weight to stiffness ratio
• very good chain retention, long durability and low noise development
• durable construction, CNC-machined
• anodised
• premium quality and great aesthetic
• designed in Great Britain, manufactured in Poland

Technology:

Oval Chainrings
Oval chainrings follow the natural physiology of humans. They maximise pedalling power the moment it is developed and minimise resistance when it is not. As a result, oval chainrings allow the rider to pedal more smoothly and stay loose on the climb.
In fact, your pedal stroke will feel " rounder" with an oval chainring than with a round chainring.
Compared to round chainrings, oval chainrings address more muscle groups - but each of them to a lesser degree. The total load of pedalling is therefore distributed over a larger muscle mass and the knees are less strained.
This has three advantages: 1. The legs remain fresher and more relaxed. 2. You can go uphill faster. 3. Spreading the load over more muscles reduces the susceptibility to cramps, even with great effort. Ultimately this will increase your riding pleasure. For MTB applications, the rear wheel traction is increased on loose and slippery surfaces, allowing you to make better progress on demanding terrain.

Manufacturer Numbers:

black / 28 tooth:

SROVTTYPE3/28BK

black / 30 tooth:

SROVTTYPE3/30BK

black / 32 tooth:

SROVTTYPE3/32BK

black / 34 tooth:

SROVTTYPE3/34BK

black / 36 tooth:

SROVTTYPE3/36BK

titanium / 28 tooth:

SROVTTYPE3/28TI

titanium / 30 tooth:

SROVTTYPE3/30TI

titanium / 32 tooth:

SROVTTYPE3/32TI

titanium / 34 tooth:

SROVTTYPE3/34TI

titanium / 36 tooth:

SROVTTYPE3/36TI

red / 28 tooth:

SROVTTYPE3/28RD

red / 30 tooth:

SROVTTYPE3/30RD

red / 32 tooth:

SROVTTYPE3/32RD

red / 34 tooth:

SROVTTYPE3/34RD

red / 36 tooth:

SROVTTYPE3/36RD

gold / 28 tooth:

SROVTTYPE3/28GL

gold / 30 tooth:

SROVTTYPE3/30GL

gold / 32 tooth:

SROVTTYPE3/32GL

gold / 34 tooth:

SROVTTYPE3/34GL

gold / 36 tooth:

SROVTTYPE3/36GL

Contents:

• 1 x absoluteBLACK Oval T-Type SRAM Transmission chainring
