DT Swiss PR 1600 SPLINE 32 Center Lock Disc 28" Wheelset

DT Swiss PR 1600 SPLINE DB 32 Road 28" wheelset - strong wheels for singular performance

The PR 1600 SPLINE wheelset from DT Swiss is made up of two durable wheels with straight pull hubs, straight spokes and particularly stable rims. Pro Lock nipple threads ensure even longer durability since the spokes are glued to the nipples, allowing the wheels to be used by heavier riders without issue. High-quality aluminium offers a light, tubeless base for your road bike. The powerful 350 hub from DT Swiss features an 18-tooth ratchet with a pressure angle of 20°. This means that the freehub can work with great precision, and is further distinguished by its long service life. The rim is tubeless ready, leaving you to decide whether to ride with or without an inner tube. The disc brake hub ensures a safe riding experience even in racing environments, making this wheelset versatile for both training and competition.

Specifications:

Application:

Road

Wheel Size:

28"

Tyre Type:

clincher tyre

Number of Spokes:

24

Brake Type:

Center Lock Disc

Tubeless System:

Tubeless Ready

Technical Information - Rim:

Rim Flange:

with hook

Dimensions (ETRTO):

18-622

Inner Width:

18 mm

Outer Width:

22 mm

Depth:

32 mm

Valve Hole Diameter:

SV/Presta (6.5 mm)

Rim Material:

aluminium

Technical Information - Front Hub:

Type:

DT Swiss 350

Over Locknut Dimension:

12 x 100 mm thru-axle

Body Material:

aluminium

Technical Information - Rear Hub:

Type:

DT Swiss 350

Over Locknut Dimension:

12 x 142 mm thru-axle

Body Material:

aluminium

Freehub Body:

Ratchet System 18

Technical Information - Lacing:

Front Lacing Pattern:

2-cross

Rear Lacing Pattern:

2-cross

Spoke Type:

DT aero comp wide / Straight pull / bladed

Spoke Material:

stainless steel (18/10)

Nipple Type:

DT ProLock / Squorx Pro Head

Nipple Size:

15 mm (length) / 2 mm (diameter)

Nipple Material:

aluminium

Approved For:

Weight Limit:

130 kg (system weight)

Air Pressure (max.):

3.5 - 9.0 bars

Recommended Tyre Width:

23 - 60 mm (0.9 - 2.35" )

Technology:

Intended use: Category 1
Suitable for predominantly paved surfaces.

SPLINE®
Straight pull hubs, straight spokes and strong rims result in a durable wheel. It can therefore be reliably used in training and competition.

Ratchet System
The robust and reliable star ratchets freehub system can be maintained easily and quickly. A no-tool concept further contributes to this, as it allows disassembly without tools. The freehub has two ratchets which engage simultaneously. This means that the contact surface is large and the point load is kept small, which relieves the material and allows the freehub to work particularly reliably and precisely.

Pro Lock
The nipple thread is coated with two-component adhesive to increase the durability of the wheels. It can still be re-trued several times without any problems, but the adhesive strength decreases slightly. The connection between the spoke and nipple cannot loosen by itself.

Colour Info:

black:

• Rim: black
• Hubs: silver
• Spokes: black
• Nipples: black

Models:

28" set (front 12x100 + rear 12x142) Shimano:

Freehub:

Shimano Road

Gearing:

8-/9-/10-/11-/12-speed

Note:

Assembly of 8-/9-/10-speed cassettes on Shimano Road freehub bodies requires a 1.85 mm spacer.

Manufacturer Numbers:

WPR1600AIDXSA04450 + WPR1600NIDMSA04452

Conversion Options:

To convert to SRAM XDR, an XDR freehub body is required.

To convert to Campagnolo, a Campagnolo freehub body is required.

Contents:

• 1 x DT Swiss PR 1600 SPLINE® DB 32 wheelset (front and rear wheel)
• 2 x DT Swiss tubeless valves
• 2 x rolls DT Swiss rim tape
