Surly Steamroller 28" Frameset

Item number: 22571
419.33€

excl. shipping cost
to the delivery destination: USA

Availability:
Choose model
Quantity:

Delivery to USA is not possible.

Surly Steamroller 28" Frameset - black/56 cm
Surly Steamroller 28" Frameset - black/56 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
Surly Steamroller 28" Frameset - pearl blackberry/53 cm
  • 100 day return period
  • Online since 1998
  • Trusted Shop 4.84 / 5.00
Due to unknown delivery times, certain varieties of this article are currently not available. More information about the current situation

Specifications:


Application: Road, Track
Wheel Size: 28"
Size: 49 cm, 53 cm, 56 cm, 59 cm, 62 cm
Frame Material: steel (4130 CrMo)
Fork Material: steel (4130 CrMo)

Technical Information - Frame:


Rear Over Locknut Dimension: 120 mm
Axle Type: 10 mm bolt-on axle
Seatpost (Ø): 27.2 mm
Seatpost Clamp (Ø): 30.0 mm
Headset: EC34/28.6 - EC34/30
Head Tube: 1 1/8"
Fork Axle to Crown: 375 mm
Fork Offset: 38 mm
Bottom Bracket Standard: BSA
Shell Width: 68 mm
Brake Mount: rim brake
Front Derailleur Mount: not possible
Cable Routing: not possible
Bottle Cage Mounts: 1

Technical Information - Fork:


Steerer Tube: 1 1/8"
Axle Type: quick release (9 x 100 mm)
Brake Mount: rim brake
Offset: 38 mm
Axle to Crown: 375 mm
Over Locknut Dimension: 100 mm
Crown Race Diameter: 30 mm
Steerer Tube Material: steel (4130 CrMo)
Blade Material: steel (4130 CrMo)

Approved For:


Weight Limit: 136 kg rider weight, 25 kg gear, 161 kg total weight
Tyre Size (max.): 38 mm, 32 mm (w/ fenders)
Chainrings: 1x
Chainring Size (max.): 50Z

Manufacturer's Notice:


When choosing your frame size note that Surly does not measure the seat tube all the way up. On frames with struts on the top tube, the measurement is taken from the middle of the bottom bracket to the top of the strut. On frames without struts, the measurement is taken from the middle of the bottom bracket to the top of the top tube.

Colour Index:


metallic lilac: purple

Models:


49 cm:
- Seat Tube Length: 490 mm
- Top Tube Length: 526.5 mm
- Effective Top Tube Length: 529.5 mm
- Head Tube Length: 83 mm
- Chainstay Length: 398 mm
- Wheelbase: 965.7 mm
- BB Drop: 70 mm
- Reach: 388.1 mm
- Stack: 504.9 mm
- Seat Tube Angle: 74.5 °
- Head Tube Angle: 72.5 °
- Standover Height: 748.5 mm
- Recommended Height: 162 - 173 cm

53 cm:
- Seat Tube Length: 530 mm
- Top Tube Length: 547 mm
- Effective Top Tube Length: 547 mm
- Head Tube Length: 109 mm
- Chainstay Length: 398 mm
- Wheelbase: 966.6 mm
- BB Drop: 70 mm
- Reach: 394 mm
- Stack: 531.3 mm
- Seat Tube Angle: 74.0 °
- Head Tube Angle: 73.0 °
- Standover Height: 780.5 mm
- Recommended Height: 162 - 183 cm

56 cm:
- Seat Tube Length: 560 mm
- Top Tube Length: 568 mm
- Effective Top Tube Length: 568 mm
- Head Tube Length: 136 mm
- Chainstay Length: 398 mm
- Wheelbase: 978.6 mm
- BB Drop: 70 mm
- Reach: 402.3 mm
- Stack: 558.8 mm
- Seat Tube Angle: 73.5 °
- Head Tube Angle: 73.5 °
- Standover Height: 807.9 mm
- Recommended Height: 170 - 190 cm

59 cm:
- Seat Tube Length: 590 mm
- Top Tube Length: 587 mm
- Effective Top Tube Length: 587 mm
- Head Tube Length: 163 mm
- Chainstay Length: 398 mm
- Wheelbase: 988.1 mm
- BB Drop: 70 mm
- Reach: 408.2 mm
- Stack: 586.4 mm
- Seat Tube Angle: 73.0 °
- Head Tube Angle: 74.0 °
- Standover Height: 835.2 mm
- Recommended Height: 188 - 198 cm

62 cm:
- Seat Tube Length: 620 mm
- Top Tube Length: 608 mm
- Effective Top Tube Length: 608 mm
- Head Tube Length: 196 mm
- Chainstay Length: 98 mm
- Wheelbase: 1009.1 mm
- BB Drop: 70 mm
- Reach: 420.6 mm
- Stack: 618.1 mm
- Seat Tube Angle: 73.0 °
- Head Tube Angle: 74.0 °
- Standover Height: 865.3 mm
- Recommended Height: 188 - 203 cm

Contents:


- 1 x Surly Steamroller frame
- 1 x Surly Steamroller fork
- 1 x Surly stainless steel seatpost clamp

Gewicht:

  • black/59 cm: 2300 g (ohne Gabel)
