Orbea WILD LT M10 Mullet Carbon 29" / 27.5" E-Mountain bike

Orbea Wild WILD LT M10 Mullet Carbon 29" / 27.5" E-Mountain bike

The WILD LT M10 Mullet Carbon 29" / 27.5" E-Mountain bike from Orbea is built for Enduro, MTB riding and gives you a modern carbon e-MTB platform with a clear focus on tough trails. Its carbon frame and carbon rear triangle use a linkage-driven single pivot kinematics for a direct, composed ride feel when the trail gets rough. The Avinox M2S mid-drive motor delivers support up to 25 km/h, while the integrated 800 Wh Avinox battery is ready for long days and big elevation. A mullet wheel setup combines a 29" front wheel with a 27.5" rear wheel for confident rollover up front and agile handling in tight sections. DT Swiss H 1900 Spline rims with 30 mm inner width are paired with a Maxxis Assegai 29 x 2.50" front tyre and Maxxis Minion DHR II 27.5 x 2.4" rear tyre for strong trail grip. Shimano XT shifting with the XT M8200 SGS Shadow Plus rear derailleur and 12-speed 10-51 cassette gives you a wide gear range for steep climbs and fast transfers. Braking is handled by Shimano Deore XT hydraulic disc brakes for controlled speed management on demanding descents. The e*thirteen Helix Core 34T crankset and 12 x 148 mm rear hub round out a solid drivetrain base. For control and comfort, the bike comes with an OC Mountain Control MC22 dropper post, Shimano SL-MT500 I-Spec EV remote, and a Fizik Aidon saddle with 145 mm width. Pedals are not included, so you can bolt on the setup that matches your riding style.

| 170 mm | S | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Travel:

170 mm

Wheel size:

29" (front), 27.5" (rear)

Crank Arm Length:

155,0 mm

Rear travel:

170 mm

| 170 mm | M | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Travel:

170 mm

Wheel size:

29" (front), 27.5" (rear)

Crank Arm Length:

155,0 mm

Rear travel:

170 mm

| 170 mm | L | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Travel:

170 mm

Wheel size:

29" (front), 27.5" (rear)

Crank Arm Length:

155,0 mm

Rear travel:

170 mm

| 170 mm | XL | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Travel:

170 mm

Wheel size:

29" (front), 27.5" (rear)

Crank Arm Length:

155,0 mm

Rear travel:

170 mm

| 170 mm | S | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork Offset:

44 mm

| 170 mm | M | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork Offset:

44 mm

| 170 mm | L | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork Offset:

44 mm

| 170 mm | XL | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork Offset:

44 mm

| 170 mm | S | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork:

Fox Racing Shox 38 Float GRIP X2 Factory

Handlebar:

OC Mountain Control MC21 Aluminum SL Rise 35

Wheelset:

DT Swiss H1900

Brake Disc Size:

200 mm (Front / Rear)

Brake Discs:

Galver Wave Disc

Stem:

OC Mountain Control MC20, 0°

Rear Shock:

Fox Racing Shox Float X2 Factory, 205 x 65 mm

| 170 mm | M | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork:

Fox Racing Shox 38 Float GRIP X2 Factory

Handlebar:

OC Mountain Control MC21 Aluminum SL Rise 35

Wheelset:

DT Swiss H1900

Brake Disc Size:

200 mm (Front / Rear)

Brake Discs:

Galver Wave Disc

Stem:

OC Mountain Control MC20, 0°

Rear Shock:

Fox Racing Shox Float X2 Factory, 205 x 65 mm

| 170 mm | L | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork:

Fox Racing Shox 38 Float GRIP X2 Factory

Handlebar:

OC Mountain Control MC21 Aluminum SL Rise 35

Wheelset:

DT Swiss H1900

Brake Disc Size:

200 mm (Front / Rear)

Brake Discs:

Galver Wave Disc

Stem:

OC Mountain Control MC20, 0°

Rear Shock:

Fox Racing Shox Float X2 Factory, 205 x 65 mm

| 170 mm | XL | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Fork:

Fox Racing Shox 38 Float GRIP X2 Factory

Handlebar:

OC Mountain Control MC21 Aluminum SL Rise 35

Wheelset:

DT Swiss H1900

Brake Disc Size:

200 mm (Front / Rear)

Brake Discs:

Galver Wave Disc

Stem:

OC Mountain Control MC20, 0°

Rear Shock:

Fox Racing Shox Float X2 Factory, 205 x 65 mm

• Carbon enduro e-MTB with mullet setup for aggressive trail riding and all-out descending
• Avinox M2S mid-drive motor with up to 1500 W power and 800 Wh integrated battery for long, powerful rides
• Linkage-driven single pivot carbon frame paired with a dropper post for confident control on steep and technical terrain
• DT Swiss H 1900 Spline wheels with Maxxis Assegai front and Minion DHR II rear tires for trail-ready grip and traction
• Shimano XT 12-speed drivetrain and Shimano Deore XT hydraulic disc brakes deliver precise shifting and strong braking performance

| 170 mm | S | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Head Tube Angle:

63.49 ,62.96 ,64.03

Stack:

628 mm

Standover Height:

769 mm

Wheelbase:

1229 mm

Reach:

432 mm

Chainstay Length:

448 mm

Seat Tube Angle:

73.59 ,73.81 ,73.38

BB Drop:

26 mm,27 mm,24 mm

Flat Bar Width:

800 mm

Recommended Rider Height:

150 - 175 cm

Seat Tube Length:

400 mm

Head Tube Length:

110 mm

Bottom Bracket Height:

352 mm

Effective Top Tube Length:

564 mm

| 170 mm | M | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Head Tube Angle:

63.5 ,62.96 ,64.04

Stack:

637 mm

Standover Height:

772 mm

Wheelbase:

1259 mm

Reach:

457 mm

Chainstay Length:

448 mm

Seat Tube Angle:

73.6 ,73.81 ,73.39

BB Drop:

26 mm,27 mm,24 mm

Flat Bar Width:

800 mm

Recommended Rider Height:

160 - 185 cm

Seat Tube Length:

405 mm

Head Tube Length:

120 mm

Bottom Bracket Height:

352 mm

Effective Top Tube Length:

594 mm

| 170 mm | L | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Head Tube Angle:

63.51 ,62.97 ,64.05

Stack:

646 mm

Standover Height:

776 mm

Wheelbase:

1288 mm

Reach:

482 mm

Chainstay Length:

448 mm

Seat Tube Angle:

73.61 ,73.82 ,73.4

BB Drop:

26 mm,27 mm,24 mm

Flat Bar Width:

800 mm

Recommended Rider Height:

170 - 195 cm

Seat Tube Length:

410 mm

Head Tube Length:

130 mm

Bottom Bracket Height:

352 mm

Effective Top Tube Length:

624 mm

| 170 mm | XL | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm:

Head Tube Angle:

63.52 ,62.98 ,64.07

Stack:

655 mm

Standover Height:

779 mm

Wheelbase:

1317 mm

Reach:

507 mm

Chainstay Length:

448 mm

Seat Tube Angle:

73.62 ,73.83 ,73.42

BB Drop:

26 mm,27 mm,24 mm

Flat Bar Width:

800 mm

Recommended Rider Height:

180 - 205 cm

Seat Tube Length:

420 mm

Head Tube Length:

140 mm

Bottom Bracket Height:

352 mm

Effective Top Tube Length:

653 mm

• | 170 mm | S | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm: U31803X6
• | 170 mm | M | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm: U31805X6
• | 170 mm | L | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm: U31807X6
• | 170 mm | XL | 44 mm | 29" (front), 27.5" (rear) | 155,0 mm: U31809X6

• 1 x Orbea WILD LT M10 Mullet Carbon 29" / 27.5" e-mountain bike


• 1 x Avinox 4A charger
