RockShox Revelation RC DebonAir Boost 29" Suspension Fork - gloss black/130 mm / 1.5 tapered / 15 x 110 mm / 42 mm

RockShox Revelation RC DebonAir Boost 29" Suspension Fork

Item number: 76134

Specifications:

Application:
Enduro, All Mountain
Wheel Size:
29"
Suspension Type:
air
Travel:
120 mm, 130 mm, 140 mm, 150 mm
Steerer Tube:
1 1/8" - 1.5" tapered
Axle Type:
thru-axle (15 x 110 mm)
Brake Mount:
disc PM7 (direct mount 180 mm)

Technical Information:

Offset:
42 mm
Steerer Tube Length:
245 mm
Steerer Tube Diameter (Stem):
28.6 mm
Steerer Tube Diameter (Crown Race):
40 mm
Axle to Crown:
531 mm (120 mm), 541 mm (130 mm), 551 mm (140 mm), 561 mm (150 mm)
Over Locknut Dimension:
110 mm
Stanchion Tube Diameter:
35 mm
Steerer Tube Material:
Aluminium
Crown Material:
Aluminium
Stanchion Tube Material:
Aluminium
Lower Tube Material:
magnesium
Dropout Material:
magnesium

Adjustment Options:

Compression:
low-speed
Rebound:
yes
Suspension Stiffness:
air pressure adjust
Remote:
no
Travel Adjustment:
no

Approved For:

Tyre Size (max.):
29 x 3.2"
Note:
For individual tyres, the tyre clearance must be checked with the fork fully compressed. It should be at least 6 mm measured from the fork crown.
Rotor Size (max.):
220 mm

Features:

  • improved and adjustable DebonAir air suspension for a smooth response
  • new designs for a modern and high-quality look
  • Motion Control damping with adjustable low-speed compression
  • 35 mm stanchions with Fast Black coating
  • external rebound adjustment
  • crown adjust

Technology:

Motion Control™:
Imagine riding on the moon. Gentle hills, crushed rock blasted out of craters. Crater. Unfortunately, you can't ride on the moon. But even on earth there is much inhospitable terrain. But we have gravity, which means you need suspension that can handle climbs and descents equally well. With Motion Control™ damping technology, exactly that is possible. You can't ride the moon, but with Motion Control you can make gravity yours.

Models:

120 mm / 1.5 tapered / 15 x 110 mm / 42 mm:
Travel:
120 mm
Steerer Tube:
1 1/8" - 1.5" tapered
Steerer Tube Diameter (Stem):
28.6 mm
Offset:
42 mm
Brake Mount:
disc PM7 (direct mount 180 mm)
Axle Type:
thru-axle (15 x 110 mm)
Model ID:
FS-RVL-RC-A3
Manufacturer Number:
00.4020.562.005

130 mm / 1.5 tapered / 15 x 110 mm / 42 mm:
Travel:
130 mm
Steerer Tube:
1 1/8" - 1.5" tapered
Steerer Tube Diameter (Stem):
28.6 mm
Offset:
42 mm
Brake Mount:
disc PM7 (direct mount 180 mm)
Axle Type:
thru-axle (15 x 110 mm)
Model ID:
FS-RVL-RC-A3
Manufacturer Number:
00.4020.562.006

140 mm / 1.5 tapered / 15 x 110 mm / 42 mm:
Travel:
140 mm
Steerer Tube:
1 1/8" - 1.5" tapered
Steerer Tube Diameter (Stem):
28.6 mm
Offset:
42 mm
Brake Mount:
disc PM7 (direct mount 180 mm)
Axle Type:
thru-axle (15 x 110 mm)
Model ID:
FS-RVL-RC-A3
Manufacturer Number:
00.4020.562.007

150 mm / 1.5 tapered / 15 x 110 mm / 42 mm:
Travel:
150 mm
Steerer Tube:
1 1/8" - 1.5" tapered
Steerer Tube Diameter (Stem):
28.6 mm
Offset:
42 mm
Brake Mount:
disc PM7 (direct mount 180 mm)
Axle Type:
thru-axle (15 x 110 mm)
Model ID:
FS-RVL-RC-A3
Manufacturer Number:
00.4020.562.008

Contents:

  • 1 x RockShox Revelation RC DebonAir 29" suspension fork
  • 1 x RockShox Maxle Stealth thru-axle
  • 2 x RockShox bottomless tokens
  • 1 x RockShox fender
  • 1 x star nut
