The Scalpel HT Carbon 3 29" Mountain Bike by Cannondale is a cross country racer

The Cannondale Scalpel HT Carbon 3 mountain bike with 29" tyres is a cross country hardtail with RockShox Remote suspension fork and Shimano XT rear derailleur. Thanks to the sophisticated geometry, which is individually-adapted to each frame size, you sit centrally in the bike and are on the move with speed both uphill and downhill. Flex areas and lower saddle rails increase comfort. You can connect the wheel sensor to the Cannondale app or other compatible devices to track your speed and distance.

Information regarding the return of batteries and electrical equipment:

Information on the return and disposal of used batteries and electrical equipment can be found here.

Specifications:

Application:

Cross Country

Wheel Size:

29"

Travel:

100 mm

Sizes:

S, M, L, XL

Frame Material:

Carbon

Components:

Frame:

Cannondale Scalpel HT Carbon, Proportional Response

Fork:

RockShox SID SL Select+ RL, DebonAir, Remote Lockout, 15 x 110 mm (Boost), 44 mm Offset

Stem:

Cannondale 2, 6061 aluminium, 31.8 mm, 7°

Handlebars:

Cannondale 2 Flat, 2014 aluminium, 31.8 mm, 8° backsweep, 3° upsweep, 760 mm

Grips:

Cannondale XC Silicone

Remote System:

RockShox OneLoc Sprint

Headset:

FSA Orbit C-40 ACB, Integrated, 1 1/8" - 1.5" , sealed angular contact ball bearings

Seatpost:

Cannondale C2 Carbon, 27.2 mm, 400 mm

Saddle:

fabric Scoop Shallow Elite, hollow steel rails (CrMo)

Crank:

Cannondale 1, BB30 83MTB, OPI SpideRing, 34 teeth, 55 mm chainline

Pedals:

none

Brakes:

Shimano M6100 hydraulic, RT64 brake rotors, 160 mm (front / rear)

Shift Lever:

Shimano SLX, 12-speed

Rear Derailleur:

Shimano XT, 12-speed

Cassette:

Shimano SLX, 10-51-tooth, 12-speed

Chain:

Shimano SLX, 12-speed

Rims:

NoTubes Crest MK4, 28 holes, tubeless ready

Spokes:

DT Swiss Competition

Front Hub:

Shimano MT410, 15 x 110 mm

Rear Hub:

Shimano MT510, 12 x 148 mm

Front Tyre:

Schwalbe Racing Ray, 29 x 2.25" , TwinSkin, tubeless ready

Rear Tyre:

Schwalbe Racing Ralph, 29 x 2.25" , TwinSkin, tubeless ready

Approved For:

Rotor Size (max.):

180 mm

Tyre Size (max.):

29 x 2.35"

Chainrings:

1x

Fork Axle to Crown Size (max.):

530 mm

Features:

• Proportional Response geometry concept: chainstay lengths and frame design are matched to frame size
• flat steering angle for confidence on fast, steep descents
• efficient uphill propulsion
• flat flex zones on the chainstays and lower saddle rails for light suspension, thus less fatigue
• suspension fork with remote
• integrated ANT+/Bluetooth wheel sensor for tracking speed and distance travelled, can be paired with Cannondale app, operates with 1 x CR2032 battery
• 55 mm chainline
• SRAM UDH universal derailleur hanger
• Speed-Release thru-axle for easy wheel change
• OPI SpideRing: 3D forged for weight savings and increased stiffness and durability
• internal cable routing with variable cable stops for use of continuous or interrupted cable housing

Technology:

OPI
One Piece Integration (OPI) refers to a 3D forging technology that makes it possible to produce components from one part in several steps, which are traditionally made up of several parts joined together.

Geometry:

S:

Recommended Height:

157 cm - 165 cm

Stack:

602 mm

Reach:

410 mm

Seat Tube Length:

390 mm

Effective Top Tube Length:

571 mm

Head Tube Length:

99 mm

Chainstay Length:

430 mm

Wheelbase:

1124 mm

Bottom Bracket Height:

315 mm

BB Drop:

62 mm

Effective Seat Tube Angle:

75°

Virtual Seat Tube Angle:

73.2°

Head Tube Angle:

67°

Standover Height:

748 mm

Stem Length:

70 mm

Handlebar Width:

760 mm

Crank Arm Length:

170 mm

M:

Recommended Height:

162 cm - 175 cm

Stack:

612 mm

Reach:

430 mm

Seat Tube Length:

440 mm

Effective Top Tube Length:

594 mm

Head Tube Length:

110 mm

Chainstay Length:

435 mm

Wheelbase:

1154 mm

Bottom Bracket Height:

315 mm

BB Drop:

62 mm

Effective Seat Tube Angle:

75°

Virtual Seat Tube Angle:

74°

Head Tube Angle:

67°

Standover Height:

785 mm

Stem Length:

80 mm

Handlebar Width:

760 mm

Crank Arm Length:

175 mm

L:

Recommended Height:

172 cm - 182 cm

Stack:

623 mm

Reach:

450 mm

Seat Tube Length:

480 mm

Effective Top Tube Length:

617 mm

Head Tube Length:

122 mm

Chainstay Length:

440 mm

Wheelbase:

1183 mm

Bottom Bracket Height:

315 mm

BB Drop:

62 mm

Effective Seat Tube Angle:

75°

Virtual Seat Tube Angle:

74.6°

Head Tube Angle:

67°

Standover Height:

814 mm

Stem Length:

80 mm

Handlebar Width:

760 mm

Crank Arm Length:

175 mm

XL:

Recommended Height:

180 cm - 195 cm

Stack:

635 mm

Reach:

470 mm

Seat Tube Length:

530 mm

Effective Top Tube Length:

640 mm

Head Tube Length:

135 mm

Chainstay Length:

445 mm

Wheelbase:

1214 mm

Bottom Bracket Height:

315 mm

BB Drop:

62 mm

Effective Seat Tube Angle:

75°

Virtual Seat Tube Angle:

75°

Head Tube Angle:

67°

Standover Height:

850 mm

Stem Length:

90 mm

Handlebar Width:

760 mm

Crank Arm Length:

175 mm

Manufacturer Number:

C25301U

Shipping Notice:

The shipment is sent pre-assembled by a forwarding agent.
The delivery time is extended by 2-5 days, depending on the overall volume of orders.
For individual consultation, please contact our customer service team.

Contents:

• 1 x Cannondale Scalpel HT Carbon 3 29" Mountain Bike
