Hope Brake Rotor, Floating 6-Bolt
Item number: 48372
Clever design principle: the Floating brake rotor by Hope
The Hope Floating Disc is a float-mounted brake rotor, which is available in numerous diameters and colours. The floating design consists of two parts, an aluminium spider attached to the hub and the actual brake rotor made of stainless steel, which is in contact with the brake pads. When the disc heats up, it expands. However, since it is not rigidly connected to the Spider, but " floating" over riveted joints, it can expand and contract freely without exerting pressure on the Spider. This prevents distortion of the brake rotor. Another advantage of floating rotors is their lower weight compared to standard brake rotors.
Technical Information:
- Mount:
- 6-bolt
- Diameter:
- 140 mm, 160 mm, 180 mm, 183 mm, 200 mm, 203 mm, 225 mm
- Design:
- 2-piece, float-mounted
- Rotor Material:
- stainless steel
- Spider Material:
- Aluminium
- Bolt Material:
- steel
Approved For:
- Brake Compatibility:
- Hope disc brakes except V2, due to a wider braking surface it is also suitable for brakes of other manufacturers*
* Due to the design of the floating brake rotor, a collision between the rivets and the brake caliper can occur with brake calipers from other manufacturers. Please check the clearance before mounting.
Features:
- for performance-oriented drivers
- laser-cut, heat-treated stainless steel brake surface
- riveted connection to aluminium spider
- Floating design is better suited to handling temperature fluctuations
- incl. mounting material
Manufacturer Number:
HBSP330Contents:
- 1 x Hope Floating brake rotor
- 6 x bolts
Weight:
- black/180 mm: 146 g
