Mavic XM 1030 Disc 27.5" Rim

The XM 1030 Disc 27.5" rim by Mavic - with ISM 4D weight tuning

The Mavic XM 1030 Disc 27.5" rim is a powerful and agile aluminium rim that can be used for Trail, All Mountain and Cross Country riding. Using the ISM 4D process, the wall thickness was modified at various points in such a way that maximum weight can be saved. The XM 1030 is 30 mm wide (inside), has eyelets and is, of course, UST Tubeless Ready.

Specifications:

Application:

All Mountain

Wheel Size:

27.5" (650B)

Tyre Type:

clincher tyre

Number of Spokes:

28, 32

Brake Type:

disc

Tubeless System:

Tubeless Ready

Technical Information:

Dimensions (ETRTO):

30-584

Inner Width:

30 mm

Outer Width:

34.5 mm

Depth:

21.2 mm

ERD:

558 mm (rim base diameter)

Valve Hole Diameter:

SV/Presta (6.5 mm)

Rim Material:

aluminium (6351)

Approved For:

Recommended Tyre Width:

2.35" - 3.0"

Features:

• powerful, agile and versatile rim sets new standards
• wider and lighter
• exclusive design
• 30 mm inner width for maximum performance
• black eyelets
• painted
• UST tubeless

Technology:

ISM 4D
ISM 4D not only noticeably reduces weight and sluggishness without sacrificing durability. The exclusive Mavic patent, with its innovative rim profile, also ensures better aerodynamics. Up to 50 g lighter for even faster climbing performance. Minimum inertia for maximum acceleration. Extra aerodynamic rim profile for less drag.

Manufacturer Numbers:

28 hole:

J3870128

32 hole:

J3870132

Contents:

• 1 x Mavic XM 1030 rim
