OneUp Components Dropper Post V2 210 mm

OneUp Components Dropper Post V2 210 mm - improved adjustment

The OneUp Components Dropper Post V2 can be described as a completely revised version of the previous OneUp post, Dropper Post 2.0, so to speak. The travel - a maximum of 210 mm in this case - can be reduced by 10 mm or by 20 mm. OneUp Components was crazy about saving as many millimetres as possible on the dropper post to ensure the lowest possible stack height and shortest possible overall length. With this dropper you can position your saddle lower than ever before.
The dropper is controlled via cable (remote not included), includes the metal pins for individual adjustment of the travel and of course the reliable sealed cartridge.
Compared to a hydraulic seatpost, the OneUp Dropper Post is insensitive to temperature and if the remote should suffer damage, you can still adjust it manually. Just take it out of the frame and operate the actuator by hand.
Unlike earlier versions, this Dropper Post can even be installed in Santa Cruz bikes with Lower Link VPP damper linkage.
You want more from a seatpost? Then pick up OneUp.

Specifications:

Application:

All Mountain, Enduro

Stroke:

210 mm

Diameter:

30.9 mm, 31.6 mm, 34.9 mm

Length:

525 mm

Setback:

0 mm

Technical Information:

Actuation:

mechanical handlebar remote

Cable Routing:

internal

Clamp:

2-bolt clamp

Compatible Saddle Rails:

7 x 7 mm (standard), 7 x 9 mm (oval)

Material:

aluminium

Approved For:

Weight Limit:

125 kg

Insertion Depth (max.):

282 mm (297 mm with actuator)

Insertion Depth (min.):

150 mm

Features:

• tons of travel (max. 210 mm) with a 243 mm stack height and a 525 mm effective length (without actuator = 15 mm)
• 375 mm maximum extension length
• travel can be adjusted by 10 or 20 mm by using metal pins that are placed in guide track (3 for 10 mm, 2x3 for 20 mm)
• cable actuated for easy installation
• reliable, sealed cartridge
• cartridge can be replaced by user
• easy to maintain at home
• compared to previous model, has a lower total length and stack, also less weight
• new DU bushing
• increased bushing overlap for increased durability
• Actuator V2.1 compatible with Santa Cruz Lower Link VPP

Models:

30.9 mm / 525 mm / SB 0 mm:

Diameter:

30.9 mm

Length:

525 mm

Setback:

0 mm

Manufacturer Number:

1C0560

31.6 mm / 525 mm / SB 0 mm:

Diameter:

31.6 mm

Length:

525 mm

Setback:

0 mm

Manufacturer Number:

1C0561

34.9 mm / 525 mm / SB 0 mm:

Diameter:

34.9 mm

Length:

525 mm

Setback:

0 mm

Manufacturer Number:

1C0662

Contents:

• 1 x OneUp Components Dropper Post V2, 210 mm
• 6 x 10 mm metal pins
• 1 x grease for tubes and seals
• 1 x cable clamp sleeve

Order Together:

• V3 Handlebar Remote
