Item number: 69593
  • 100 day return period
  • Online since 1998
  • Trusted Shop 4.89 / 5.00
One of the most successful and hardest working RockShox forks of all time takes advantage of the innovations of the latest SID. A chassis that combines Reba's classic XC performance with light trail work and a proven Motion Control™ RL shock rounds out the package, making Reba as capable as it gets.

Specifications:

Application:
Cross Country
Wheel Size:
29"
Suspension Type:
air
Travel:
100 mm, 120 mm
Steerer Tube:
1 1/8" - 1.5" tapered
Axle Type:
thru-axle (15 x 100 mm)
Brake Mount:
disc PM6 (direct mount 160 mm)

Technical Information:

Offset:
51 mm
Steerer Tube Length:
245 mm (100 mm), 265 mm (120 mm)
Steerer Tube Diameter (Stem):
28.6 mm
Steerer Tube Diameter (Crown Race):
40 mm
Axle to Crown:
506 mm (100 mm), 526 mm (120 mm)
Over Locknut Dimension:
100 mm
Stanchion Tube Diameter:
32 mm
Steerer Tube Material:
aluminium
Crown Material:
aluminium
Stanchion Tube Material:
aluminium
Lower Tube Material:
magnesium

Adjustment Options:

Compression:
low-speed (Lockout)
Rebound:
yes
Suspension Stiffness:
air pressure adjust

Approved For:

Tyre Size (max.):
29 x 2.5"
Note:
For individual tyres, the tyre clearance must be checked with the fork fully compressed. It should be at least 6 mm measured from the fork crown.
Rotor Size (max.):
220 mm

Features:

  • Motion Control™
  • external rebound adjustment
  • TwistLoc and OneLoc remote compatible
  • reworked design
  • low-speed compression shock adjustment until lockout
  • crown adjust

Technology:

Motion Control™:
Imagine riding on the moon. Gentle hills, crushed rock blasted out of craters. Crater. Unfortunately, you can't ride on the moon. But even on earth there is much inhospitable terrain. But we have gravity, which means you need suspension that can handle climbs and descents equally well. With Motion Control damping technology, exactly that is possible. You can't ride the moon, but with Motion Control you can make gravity yours.

Solo Air™:
Solo Air™ is like a Buddhist monk. The enlightened design allows the positive and negative air chambers of your suspension fork to be filled with air at the same time using only one Schrader valve. So there is a perfect balance between them, like Yin and Yang. For a comfortable and predictable ride, you can adjust the easiest suspension fork on the market in seconds.

Manufacturer Numbers:

100 mm / 1.5 tapered / 15 x 100 mm:
00.4020.145.008
120 mm / 1.5 tapered / 15 x 100 mm:
00.4020.145.010

Contents:

  • 1 x RockShox Reba RL Solo Air 29" suspension fork
  • 1 x RockShox Maxle Stealth thru-axle
  • incl. star nut


Models:

  • gloss black/100 mm / 1.5 tapered / 15 x 100, out of stock
    345.35€
  • gloss black/120 mm / 1.5 tapered / 15 x 100, in stock
    328.04€
