Specifications:

Application:

Road

Wheel Size:

28"

Sizes:

52 cm, 54 cm, 56 cm

Frame Material:

carbon (HMF)

Fork Material:

carbon (HMF)

Components:

Frame:

Scott Addict Disc, Carbon (HMF)

Fork:

Scott Addict Disc, Carbon (HMF), 1 1/4" - 1.5"

Stem:

Syncros RR2.0 1 1/4" , 31.8 mm, four-way screw clamp

Handlebars:

Syncros Creston 2.0 Compact, 31.8 mm, aluminium

Headset:

Acros AIF-1112, 1 1/4" - 1.5" tapered

Seatpost:

Syncros Duncan 1.0, 27.2 mm, 350 mm, Setback: 10 mm (52 cm, 54 cm), 20 mm (56 cm)

Saddle:

Syncros Tofino Regular 2.0 Channel

Crank:

SRAM Rival, 33-46 teeth

Pedals:

none

Brakes:

SRAM Rival eTap AXS, Flat Mount, hydraulic, 160 mm

Shift/Brake lever:

SRAM Rival eTap AXS, hydraulic, 2x12-speed

Rear Derailleur:

SRAM Rival eTap AXS, 12-speed

Front Derailleur:

SRAM Rival eTap AXS

Cassette:

SRAM Rival XG-1250, 10-36 teeth

Chain:

SRAM Rival

Wheels:

Syncros RP2.0 Disc / Syncros Axle

Tyres:

Schwalbe One, 700x32C

Approved For:

Weight Limit:

120 kg (system weight)

Features:

• endurance carbon road bike
• replaceable derailleur hanger
• internal cable routing
• optimised tube structures and layer alignment in the frame using computer-based Evo-Lap technology

Geometry:

52 cm:

Stack:

551.6 mm

Reach:

387 mm

Seat Tube Length:

505 mm

Effective Top Tube Length:

540 mm

Head Tube Length:

125 mm

Chainstay Length:

420 mm

Wheelbase:

1005 mm

Bottom Bracket Height:

275.3 mm

BB Drop:

70 mm

Standover Height:

775 mm

Seat Tube Angle:

74.5°

Head Tube Angle:

72°

Stem Length:

103 mm

Handlebar Width:

420 mm

Crank Arm Length:

172.5 mm

54 cm:

Stack:

572.4 mm

Reach:

390.9 mm

Seat Tube Length:

525 mm

Effective Top Tube Length:

555 mm

Head Tube Length:

145 mm

Chainstay Length:

420 mm

Wheelbase:

1010.6 mm

Bottom Bracket Height:

275.3 mm

BB Drop:

70 mm

Standover Height:

790 mm

Seat Tube Angle:

74°

Head Tube Angle:

72.5°

Stem Length:

113 mm

Handlebar Width:

420 mm

Crank Arm Length:

172.5 mm

56 cm:

Stack:

593.3 mm

Reach:

394.3 mm

Seat Tube Length:

545 mm

Effective Top Tube Length:

570 mm

Head Tube Length:

165 mm

Chainstay Length:

420 mm

Wheelbase:

1015.4 mm

Bottom Bracket Height:

275.3 mm

BB Drop:

70 mm

Standover Height:

812 mm

Seat Tube Angle:

73.5°

Head Tube Angle:

73°

Stem Length:

113 mm

Handlebar Width:

420 mm

Crank Arm Length:

172.5 mm

Manufacturer Number:

2864220

Shipping Notice:

The shipment is sent pre-assembled by a forwarding agent.
The delivery time is extended by 2-5 days, depending on the overall volume of orders.
For individual consultation, please contact our customer service team.

Contents:

• 1 x Scott Addict 10 Carbon Road Bike
