Fox Racing Shox SLS Super Light Steel Coil for 72.5 - 76 mm Stroke

The Fox Racing Shox SLS Super Light steel coil for shocks with 72.5 to 76 mm stroke

This Fox Racing Shox SLS Super Light steel coil weighs less than a titanium coil and is suitable for compatible shocks with 72.5 to 76 mm stroke. The coil itself has a stroke of 80 mm, this must necessarily be greater than the stroke of the shock. The specially developed surface treatment and manufacturing process reduce stresses on the coil, allowing it to withstand higher loads than standard steel coils. The relatively low material thickness and number of coils make an additional contribution to weight reduction.

Specifications:

Application:

Downhill, Enduro, All Mountain

Rear Shock (Size x Travel):

241 x 76 mm (9.50" x 3.00" ), 225 x 72.5 mm, 225 x 75 mm, 250 x 72.5 mm, 250 x75 mm

Stroke:

80 mm (3.15" )

Inner Diameter:

35 mm (1.385" )

Compatibility:

• Fox DHX2 rear shock
• Fox DHX rear shock
• Fox VAN shock
• Marzocchi Bomber CR shock

Note from the manufacturer:

Depending on the shock model, it may happen that a coil is too long or too short. Therefore, also consider the coil length when making your choice.

Models:

225 lbs:

Coil Length:

137 mm

Spring Rate:

225 lbs/inch

Manufacturer Number:

033-22-040

250 lbs:

Coil Length:

141 mm

Spring Rate:

250 lbs/inch

Manufacturer Number:

033-22-041

275 lbs:

Coil Length:

139 mm

Spring Rate:

275 lbs/inch

Manufacturer Number:

033-22-042

300 lbs:

Coil Length:

142 mm

Spring Rate:

300 lbs/inch

Manufacturer Number:

033-22-043

325 lbs:

Coil Length:

145 mm

Spring Rate:

325 lbs/inch

Manufacturer Number:

033-22-044

375 lbs:

Coil Length:

150 mm

Spring Rate:

375 lbs/inch

Manufacturer Number:

033-22-046

400 lbs:

Coil Length:

153 mm

Spring Rate:

400 lbs/inch

Manufacturer Number:

033-22-047

425 lbs:

Coil Length:

156 mm

Spring Rate:

425 lbs/inch

Manufacturer Number:

033-22-048

450 lbs:

Coil Length:

160 mm

Spring Rate:

450 lbs/inch

Manufacturer Number:

033-22-049

475 lbs:

Coil Length:

163 mm

Spring Rate:

475 lbs/inch

Manufacturer Number:

033-22-050

500 lbs:

Coil Length:

135 mm

Spring Rate:

500 lbs/inch

Manufacturer Number:

033-22-051

525 lbs:

Coil Length:

168 mm

Spring Rate:

525 lbs/inch

Manufacturer Number:

033-22-063

550 lbs:

Coil Length:

139 mm

Spring Rate:

550 lbs/inch

Manufacturer Number:

033-22-052

575 lbs:

Coil Length:

168 mm (6.6" )

Spring Rate:

575 lbs/inch

Manufacturer Number:

033-22-064

Contents:

• 1 x Fox Racing Shox SLS Super Light steel coil
