SRAM Apex 1 HRD FM Disc Brake with Dropper Actuator

The Apex 1 HRD FM disc brake with Dropper Actuator by SRAM harmonises with your dropper seatpost

With this Apex 1 hydraulic disc brake with flat mount, you can brake reliably in any situation and also remotely control your mechanical telescopic seatpost. The Dropper Actuator, a vario-post remote control directly on the brake lever, ensures a tidy cockpit and allows you to operate your mechanically lowerable seatpost at any time without having to reach for it. The reach of the ergonomic brake lever is adjustable and, thanks to the proven HydroR™ system, you will come to a safe stop even with little force. This way, you can recklessly give it your all on the terrain!

Specifications:

Series:

Apex

Application:

Cyclocross, Gravel

Type:

hydraulic, 2 pistons

Actuation:

DOT 5.1

Front Hose Length:

950 mm

Technical Information - Caliper:

Caliper Mount:

flat mount

Pistons:

2

Pads:

organic

Design:

2-piece

Calliper Material:

Aluminium

Hose Connection:

banjo

Technical Information - Lever:

Adjustment Options:

reach adjust (with tools)

Mount:

clamp (closed)

Design:

left (side-specific)

Brake Lever Material:

Aluminium

Brake Lever Housing Material:

Composite

Features:

• with remote control for mechanical telescopic seatpost
• tidy cockpit
• only for 1x drivetrains
• intuitive, ergonomic operation from all hand positions
• high braking power with low effort
• award winning HydroR braking system
• forged aluminium brake caliper
• reach adjust with tools
• recommended brake rotor Centerline 1-piece
• 160 mm brake rotor recommended for most applications
• 20 mm offset

Technology:

Reach Adjust:
The fit and ergonomics of the brake lever is a very personal matter. Riders have personal position preferences as well as individual hand sizes and finger lengths. With the reach adjustment, the lever can be easily adjusted - for maximum control with just one finger.

Manufacturer Number:

00.5018.155.000

Contents:

• 1 x SRAM Apex 1 HRD FM disc brake
• 1 x SRAM brake lever with Dropper Actuator
• 1 x SRAM brake hose, 950 mm
• 1 x pairs SRAM organic brake pads
• 1 x SRAM brake rotor adapter
• 2 x SRAM bolts
• 1 x SRAM olives
• 1 x SRAM insert
• 1 x SRAM pad spacer
• 1 x SRAM bleed block

Order Together:

• SRAM Centerline Rounded 6-bolt Brake Rotor 1-piece
