BEAST Components GR40 Center Lock Disc Carbon 28" Wheelset

Item number: 81282

Product Description

The GR40 by BEAST Components is a gravel wheelset for race-oriented gravel bikers. The 40 mm high carbon rims shine with excellent aerodynamics. Thanks to the reinforced rim flange, you can ride wide tyres with low pressure without any issue. DT Swiss Center Lock hubs guarantee you absolute control, both on and off paved roads.

Specifications:

Application:: Gravel
Wheel Size:: 28"
Tyre Type:: clincher tyre
Number of Spokes:: 24
Brake Type:: Center Lock Disc
Tubeless System:: Tubeless Ready

Technical Information - Rim:

Type:: GR40
Rim Flange:: hookless
Dimensions (ETRTO):: 25-622
Inner Width:: 25 mm
Outer Width:: 30.4 mm
Depth:: 40 mm
ERD:: 557 mm (rim base)
Valve Hole Diameter:: SV/Presta (6.5 mm)
Rim Material:: Carbon

Technical Information - Front Hub:

Type:: DT Swiss 240
Over Locknut Dimension:: 12 x 100 mm thru-axle
Bearings:: steel bearings
Body Material:: aluminium

Technical Information - Rear Hub:

Type:: DT Swiss 240
Over Locknut Dimension:: 12 x 142 mm thru-axle
Bearings:: steel bearings
Body Material:: aluminium
Freehub Body:: Ratchet EXP 36

Technical Information - Lacing:

Front Lacing Pattern:: 2-cross
Rear Lacing Pattern:: 2-cross
Spoke Type:: Sapim CX-Ray
Spoke Material:: stainless steel
Nipple Type:: Sapim internal
Nipple Material:: aluminium

Colour Info:

UD carbon-black:

Rims: black with grey decals
Hubs: black red
Spokes: black
Nipples: black

Models:

28" set (front 12x100 + rear 12x142) Shimano:

Freehub:: Shimano Road
Gearing:: 8-/9-/10-/11-/12-speed
Note:: Assembly of 8-/9-/10-speed cassettes on Shimano Road freehub bodies requires a 1.85 mm spacer.
Manufacturer Number:: W2SGR402428US1

28" set (front 12x100 + rear 12x142) SRAM XDR:

Freehub:: SRAM XDR
Gearing:: 11-/12-speed
Note:: A 1.8 mm spacer is required to mount XD cassettes on an XDR freehub.
Manufacturer Numbers:: W2XGR402428US1

Weight:

UD carbon-black/Non Boost/Non Boost/142 mm/100 mm/28"/Shimano Road/100 mm/Shimano Road/100 mm/142 mm: 1460 g

Manufacturer:

Black East GmbH
Hermann-Mende-Straße 5-7
01099 Dresden
Germany
info@beast-components.de

Models:

UD carbon-black/Non Boost/Non Boost/142 mm/100 mm/28"/Shimano Road/100 mm/Shimano Road/100 mm/142 mm, no longer available
1,270.00€

Customer Reviews (2)

Information on the Collection of Customer Ratings

Our website displays reviews from before and after 28.05.2022. As of 28.05.2022, only reviews stemming from verified purchases will be published on our website, which means that an order number must also be provided along with the review. We will only display the review and/or rating after successful verification of the order number. All reviews stemming from a verified purchase are given a green check mark, which applies to all verified reviews prior to and following 28.05.2022. Before 28.05.2022, reviews were also published from customers who did not purchase the reviewed product(s) from us. These reviews have not been given a green check mark. We publish all properly submitted reviews.

5.0/5.0

Give us your opinion on this product.

5 out of 5 stars

by Stefan D. on 21.02.2023 item: UD carbon-black/Non Boost/Non Boost/142 mm/100 mm/28"/SRAM XDR/100 mm/SRAM XDR/100 mm/142 mm

Hab diesen Laufradsatz nun eine Weile im Einsatz.
Sieht sehr gut aus, fährt sich super und macht auch Offroad eine sehr gute Figur.
Einziges Manko, Seitenwind ist nicht so der Freund dieser Beast’er aber das Problem haben alle mit der Felgenhöhe.
Hochwertig und sauber verarbeitete Laufräder, Made in Germany was will man mehr.
Kann sie absolut empfehlen und würde sie wieder kaufen.
Für die Graveler unter uns die gerne mit viel zu viel Gepäck auf große Abenteuer gehen, sie stemmen jedes Gewicht und haben laut Hersteller kein Gewichtslimit.

Is this review helpful?
5 out of 5 stars

by Christopher H. on 12.06.2021 item: UD carbon-black/Non Boost/Non Boost/142 mm/100 mm/28"/Shimano Road/100 mm/Shimano Road/100 mm/142 mm

Ich kenne keinen wertigeren Laufradsatz als diesen. Die Verarbeitung und Optik der Felgen suchen ihresgleichen.
Auch die Aufkleber liessen sich problemlos entfernen.
Was mir aufgefallen ist, dass die neuen EXP Naben ein deutlich lauteres Freilaufgeräusch haben als meine anderen DT Swiss Ratchet Naben. Zudem ist der Klang gleichmäßiger (kein eierndes Geräusch mehr).
Wer einen hochwertigen Laufradsatz Made in Germany sucht wird hier fünfig.

Is this review helpful?
