The ZS56/28.6 headset top assembly from Cane Creek's 40 series is equipped with galvanised bearings that provide a high level of corrosion protection, thus ensuring increased durability. The sealed cartridge bearings are equipped with hardened steel balls. The 40 series is the ideal top part of a durable and lightweight headset, and offers a perfect balance of performance and price.

Use:
Designed for 1.5" upper head tube diameters combined with 1 1/8" , 1 1/8" - 1.5" tapered or 1 1/8" - 1 1/4" tapered forks.

Specifications:

Application:

MTB

Top Cup:

1.5"

Steerer Tube:

1 1/8" , 1 1/8" - 1.5" tapered, 1 1/8" - 1 1/4" tapered

Design:

Zero Stack (ZS)

Technical Information:

Material:

aluminium (6061-T6)

Bearings:

angular contact cartridge, sealed; zinc-plated

Bearing Seat:

45° x 36°

Top Stack Height:

8 mm

Top Outer Diameter:

56 mm

Top Inner Diameter:

28.6 mm

Standardized Headset Identification System (S.H.I.S.):

In order to clarify and bring uniformity to a sea of headset standards, manufacturers Acros, Cane Creek, Hope, Race Face, Reset Racing and Ritchey have agreed upon using a shared nomenclature, which will likely include more participating companies in the future. This system takes into account a combination of frame and fork dimensions. Both the top and bottom parts of the headset are marked by two alphanumeric identifiers. The first identifier indicates the type of headset (External Cup, Zero Stack, Integrated) and head tube diameter. The second identifier - separated from the first by a backslash - indicates the diameter of the steerer tube. When referring to a complete headset, the specifications of both top and bottom parts must be combined.

Nomenclature:

EC:

Bearings contained within headset cups that are located outside of the frame (External Cup)

ZS:

Bearings contained within pressed-in headset cups where the cup and bearings rest inside the frame (Zero Stack)

IS:

Bearings that fit directly into a bonded or machined interface that is integrated into the frame (Integrated)

Manufacturer Number:

BAA0912K

Contents:

• 1 x Cane Creek 40-series headset top assembly
